6x16 Inch ESD Anti Static Bags Special Four Layer Structure Laminated Material

6x16 Inch ESD Anti Static Bags Special Four Layer Structure Laminated Material

  • 6x16 Inch ESD Anti Static Bags Special Four Layer Structure Laminated Material
  • 6x16 Inch ESD Anti Static Bags Special Four Layer Structure Laminated Material
  • 6x16 Inch ESD Anti Static Bags Special Four Layer Structure Laminated Material
6x16 Inch ESD Anti Static Bags Special Four Layer Structure Laminated Material
Product Details:
Place of Origin: China
Brand Name: TOP
Model Number: T-0-0616
Payment & Shipping Terms:
Minimum Order Quantity: 1000pcs
Price: Negotiable
Packaging Details: 50-100pcs/bags, 5-50bags/carton and then packed in pallets
Delivery Time: within 10 days
Supply Ability: 500000pcs/day
Contact Now
Detailed Product Description
Industrial Use: Electronic Packing, Pc Board,IC Integrated Circuit Sealing And Handle: Self Adhesive ,heat Seal
Material: Laminated Material Material Structure: Apet/cpp Or Apet/cpe,
Color: Silver Semitransparent Style Of Bag: Open Top/zip Lock/self-adhesive/guesset/cubic
Feature: Antistatic Printing: Could Be Printed According To Buyer's Requirement
Resistance: 10^8_10^11ohm Or 10^6-10^9ohm SIZE: 6X16INCH
High Light:

anti static packaging

,

anti static shielding bags

6x16 Inch printed ESD Anti -Static Shielding Bags and rolls



1. This kind of bag can keep static-sensitive components away from the potential static danger to the largest extent. Its special four layer structure can create such effect as an inductive cover to separate the goods inside from the static field.



2. The inner layer is made from ethane which can remove the static and avoid static generation inside the bag.



3. This kind of hot seal bags is transparent, so the goods inside can be easily recoginzed from outside. The surface resitance is 10^8_10^11.



4. layers: Antistatic agent-polyester layer-aluminum shielding-anti-static polyethylene-Anti-static Layer.





Product Description:



Product Name Anti-static shielding bag, ESD barrier bag
Material

Out-layer: BOPP, PET, Matt-PET, PA, VMPET, VMCPP, etc

Mid-layer: PET, VMPET, VMCPP, PAPER, AL, PA, etc

Inner-layer: CPP, PE, White PE, VMPET, etc

Surface Resistance 10^8-10^11 Ohm
Size Customized size or our standard size
Thickness Standard 0.075mm(3mil) or customized
Style Flat, stand-up
Closure Zip-lock, heat-seal, open top
Seam 2 or 3 sides with 5mm seal
Usage Pack and store the electronic products that sensitive to static, such as PC board, computer mainboard, sound card, VGA card, IC integrated circuit, network card, CD driver and other electronic devices or components
Feature Semi-transparent, anti-static, dustproof, moistureproof
Printing Customized printing available
Sample

In stock blank sample for free;

Customized sample will be charged and taking 7 days, refund is available after the confirmation of order.

MOQ 2000pcs
Package 50~200pcs/bag and 5-50bags/carton, as requested
Payment terms

T/T, L/C, Western Union

30% deposit and 70% balance before shipment

Delivery time Usually within 15 days, depends on quantity and any customized service






Product Parameters:



No. Item Test Standard Test Result
1 Metal layer resistance ASTMD-257 <0.1Ω
2 Shielding capability MIL-B*81705-C >60 db
3 Shielding voltage EIA541 <10 V
4 Tensile strength FTMS101 >24 pound (10 kg)
5 Inner surface resistivity ASTMD-257 10^8-11Ω
6 Outer surface resistivity ASTMD-257 10^8-11Ω
7 Heat seal temperature °C 210±10
8 Heat seal time Sec. 0.3-0.5
9 Heat seal pressure Pa 40-60
10 Seal strength GB/96-04-10 >3kg/cm
11 Appearance GB/96-04-10 No delamination, no wrinkle, no warp, no break, no foreign particle adherence, air bubble beyond sealing ≤3mm
12 Size GB/96-04-10 Thickness±10%, length±3mm, Width ±3mm






Product Details:

6x16 Inch ESD Anti Static Bags Special Four Layer Structure Laminated Material 06x16 Inch ESD Anti Static Bags Special Four Layer Structure Laminated Material 1

6x16 Inch ESD Anti Static Bags Special Four Layer Structure Laminated Material 2


Product application:

6x16 Inch ESD Anti Static Bags Special Four Layer Structure Laminated Material 3


Packing:

6x16 Inch ESD Anti Static Bags Special Four Layer Structure Laminated Material 4


About us:

6x16 Inch ESD Anti Static Bags Special Four Layer Structure Laminated Material 56x16 Inch ESD Anti Static Bags Special Four Layer Structure Laminated Material 66x16 Inch ESD Anti Static Bags Special Four Layer Structure Laminated Material 76x16 Inch ESD Anti Static Bags Special Four Layer Structure Laminated Material 8


Contact us:

6x16 Inch ESD Anti Static Bags Special Four Layer Structure Laminated Material 9


General FAQ:



Q1: Are you a manufacturer or trading company?

A1: We are a factory from the production and processing of raw materials to the manufacture and export of products.





Q2: What's your main products?

A2: Anti-static packaging bags, mailers for express delivery, thermal insulation building materials, etc.





Q3: Can you make the accurate quotation? And how long will it take?

A3: Yes, we can. Before we make an accurate quotation, we need as much information as possible. For instance, mailer bag: we need to know bags’ shape, usage, material, color, size, quantity, thickness, surface finishing, etc. If the information you provide is sufficient, we can give you a quotation within 3 hours during working hours and 12 hours during non-working hours.





Q4: Can you provide samples? / Can I get a sample for reference?

A4: Yes, we can provide you with a blank sample for free, but you need to bear the freight. For more info please contact us.





Q5: Can you provide OEM service?

A5: Of course, we offer customized printing and packaging. Please contact us for details.





Q6: What is the delivery time and shipping method?

A6: It depends on your order quantity and shipping method. We usually use sea shipment, air shipment and express.





Q7: What terms of payment do you accept?

A7: We accept T/T and L/C. Other payment methods like Western Union could be considered, please contact us for more information.
